Teknisk spesifikasjon

Usage	Operator system for garage doors in private use
Maximum dimensions of up-and-over doors	- Width up to 5000 mm - Weight up to 185 kg
Maximum dimensions of sectional doors	- Width up to 5500 mm - Weight up to 185 kg
Maximum dimensions of up-and-over doors and canopy doors	- Width up to 5000 mm - Height up to 2250 mm - Weight up to 185 kg
Maximum cycles with standard rail 0.8 mm	Up to 32 starts per day
Maximum cycles with rail 1.2 mm	Up to 40 starts per day
Connection for battery backup	✔
Output for accessories	✔ 24V, 250 mA
Connection for extension modules	✔ {except EM 131)
Strømforsyning	230 V
Absorbed current	1.1 A
Power consumption	250 W
Power consumption in STAND-BY mode	0.6 W
Push and pull force	850 N
Door travel speed	Maximally 23.5 cm/s
Kapslingsgrad	IP20
Integrated radio receiver	✔ 868 MHz
Integrated lighting	✔ LED, 2 modules with 10 LEDs
Dimensions	360 × 135 × 335 mm
Tillatt omgivelsestemperatur	-20°C ÷ +60°C
Weight	7.4 kg
