LukkLukk
| Strømforsyning | 230 V |
|---|---|
| Traction | 600 N |
| Maximum number of duty cycles per hour at rated load | 20 starts per hour |
| Maximum number of duty cycles without a break at rated load | 8 starts |
| Power consumption at rated load | 140 W |
| Closed current | <2 W |
| Installation height drive rail | 40 mm |
| Noise level at a distance of 2 m | ≤69 dB |
| Possibility to connect electric lock | ✔ |
| Door travel speed | Maximal 21 cm/s during opening Maximal 13 cm/s during closing |
| Kapslingsgrad | IP20 |
| Integrated radio receiver | ✔ 433 MHz |
| Built-in operator lighting | ✔ Bulb E14, maximal 40 W |
| Dimensions | 100 × 283 × 362 mm |
| Tillatt omgivelsestemperatur | -20°C ÷ +50°C |
