LukkLukk
| Radio frequency | 868.8 MHz |
|---|---|
| Rated voltage range | AC/DC 12 - 14 Volt ±20% |
| Tillatt omgivelsestemperatur | -20°C ÷ +70°C |
| Max. current consumption 12 Vdc | 80 mA |
| Max. current consumption 24 Vac | 175 mA |
| Switching capacity (ohmic load) | 1.0 A, DC 30 V 0.5 A, AC 125 V |
| Area of application | Dry, fully enclosed interiors |
| Memory slots | 112 radio codes |
| Dimensjoner | 109 × 40 × 32 mm |
| Weight | 55 g |
| Operating mode | Tipp |
