This control board is compatible with the following motors:
This control board is compatible also with motors twist 200, twist 200E and twist 200EL sold under other names like Aperto twist 200, Aperto twist 200E or Aperto twist 200EL
If you do not need a complete control board, then please remember, that you can also purchase individual parts like:
If you are interested in any of these parts, please do not hesitate to contact before buying.
| Number of supported motors | 1 or 2 motors |
|---|---|
| Power supply of control board | 230V |
| Voltage of output for motors | 24V |
| Supported accessories | - Photocells - Safety edge (only with an external evaluation unit) - Flashing lamp - External receivers (24V, max. 1A), floating relay contact - TorMinal - Electric lock |
| Integrated radio receiver | ✘ Must be purchased separately |
| Input for radio receiver | ✔ Universal third-party radio receivers |
| Number of radio channels | 2 |
| Kapslingsgrad | IP65 |
| Housing included in delivery | ✔ |
| Tillatt omgivelsestemperatur | -20°C ÷ +70°C |
| Dimensions | 180 × 254 × 90 mm |
